PART NO. | Picture | Product Status | Power (W) | VZ @ IZT (V) Nom | VZ @ IZT (V) Min | VZ @ IZT (V) Max | Max VF@ IF=200mADC | Tolerance (%) | Tj (°C) | Packages | CAD模型 | 電路圖 |
|
DL4728(A)
|
![]() |
Active | 1 | 3.3 | 3.1 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4729(A)
|
![]() |
Active | 1 | 3.6 | 3.4 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4730(A)
|
![]() |
Active | 1 | 3.9 | 3.7 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4731(A)
|
![]() |
Active | 1 | 4.3 | 4 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4732(A)
|
![]() |
Active | 1 | 4.7 | 4.4 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4733(A)
|
![]() |
Active | 1 | 5.1 | 4.8 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4734(A)
|
![]() |
Active | 1 | 5.6 | 5.2 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4735(A)
|
![]() |
Active | 1 | 6.2 | 5.8 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4736(A)
|
![]() |
Active | 1 | 6.8 | 6.4 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4737(A)
|
![]() |
Active | 1 | 7.5 | 7 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4738(A)
|
![]() |
Active | 1 | 8.2 | 7.7 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4739(A)
|
![]() |
Active | 1 | 9.1 | 8.5 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4740(A)
|
![]() |
Active | 1 | 10 | 9.4 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4741(A)
|
![]() |
Active | 1 | 11 | 10.4 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4742(A)
|
![]() |
Active | 1 | 12 | 11.4 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4743(A)
|
![]() |
Active | 1 | 13 | 12.4 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4744(A)
|
![]() |
Active | 1 | 15 | 13.8 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4745(A)
|
![]() |
Active | 1 | 16 | 15.3 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4746(A)
|
![]() |
Active | 1 | 18 | 16.8 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4747(A)
|
![]() |
Active | 1 | 20 | 18.8 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4748(A)
|
![]() |
Active | 1 | 22 | 20.8 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4749(A)
|
![]() |
Active | 1 | 24 | 22.8 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4750(A)
|
![]() |
Active | 1 | 27 | 25.1 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4751(A)
|
![]() |
Active | 1 | 30 | 28 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4752(A)
|
![]() |
Active | 1 | 33 | 31 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4753(A)
|
![]() |
Active | 1 | 36 | 34 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4754(A)
|
![]() |
Active | 1 | 39 | 37 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4755(A)
|
![]() |
Active | 1 | 43 | 40 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4756(A)
|
![]() |
Active | 1 | 47 | 44 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4757(A)
|
![]() |
Active | 1 | 51 | 48 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4758(A)
|
![]() |
Active | 1 | 56 | 52 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4759(A)
|
![]() |
Active | 1 | 62 | 58 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4760(A)
|
![]() |
Active | 1 | 68 | 64 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4761(A)
|
![]() |
Active | 1 | 75 | 70 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4762(A)
|
![]() |
Active | 1 | 82 | 77.9 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4763(A)
|
![]() |
Active | 1 | 91 | 86.45 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
DL4764(A)
|
![]() |
Active | 1 | 100 | 95 | null | 1.2 | 5 | 200°C | DO-213AA (1.0W) | ||
|
ZMM55C2V4
|
![]() |
Active | 0.5 | 2.4 | 2.28 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C2V7
|
![]() |
Active | 0.5 | 2.7 | 2.5 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C3V0
|
![]() |
Active | 0.5 | 3 | 2.8 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C3V3
|
![]() |
Active | 0.5 | 3.3 | 3.1 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C3V6
|
![]() |
Active | 0.5 | 3.6 | 3.4 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C3V9
|
![]() |
Active | 0.5 | 3.9 | 3.7 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C4V3
|
![]() |
Active | 0.5 | 4.3 | 4 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C4V7
|
![]() |
Active | 0.5 | 4.7 | 4.4 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C5V1
|
![]() |
Active | 0.5 | 5.1 | 4.8 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C5V6
|
![]() |
Active | 0.5 | 5.6 | 5.2 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C6V2
|
![]() |
Active | 0.5 | 6.2 | 5.8 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C6V8
|
![]() |
Active | 0.5 | 6.8 | 6.4 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C7V5
|
![]() |
Active | 0.5 | 7.5 | 7 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C8V2
|
![]() |
Active | 0.5 | 8.2 | 7.7 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C9V1
|
![]() |
Active | 0.5 | 9.1 | 8.5 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C10
|
![]() |
Active | 0.5 | 10 | 9.4 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C11
|
![]() |
Active | 0.5 | 11 | 10.4 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C12
|
![]() |
Active | 0.5 | 12 | 11.4 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C13
|
![]() |
Active | 0.5 | 13 | 12.4 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C15
|
![]() |
Active | 0.5 | 15 | 13.8 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C16
|
![]() |
Active | 0.5 | 16 | 15.3 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C18
|
![]() |
Active | 0.5 | 18 | 16.8 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C20
|
![]() |
Active | 0.5 | 20 | 18.8 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C22
|
![]() |
Active | 0.5 | 22 | 20.8 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C24
|
![]() |
Active | 0.5 | 24 | 22.8 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C27
|
![]() |
Active | 0.5 | 27 | 25.1 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C30
|
![]() |
Active | 0.5 | 30 | 28 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C33
|
![]() |
Active | 0.5 | 33 | 31 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C36
|
![]() |
Active | 0.5 | 36 | 34 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C39
|
![]() |
Active | 0.5 | 39 | 37 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C43
|
![]() |
Active | 0.5 | 43 | 40 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C47
|
![]() |
Active | 0.5 | 47 | 44 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C51
|
![]() |
Active | 0.5 | 51 | 48 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C56
|
![]() |
Active | 0.5 | 56 | 52 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C62
|
![]() |
Active | 0.5 | 62 | 58 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C68
|
![]() |
Active | 0.5 | 68 | 64 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
ZMM55C75
|
![]() |
Active | 0.5 | 75 | 70 | null | 1.5 | 5 | 175°C | DO-213AA (0.5W) | ||
|
SMA4728A
|
![]() |
Active | 1 | 3.3 | 3.135 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4729A
|
![]() |
Active | 1 | 3.6 | 3.42 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4730A
|
![]() |
Active | 1 | 3.9 | 3.705 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4731A
|
![]() |
Active | 1 | 4.3 | 4.085 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4732A
|
![]() |
Active | 1 | 4.7 | 4.465 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4733A
|
![]() |
Active | 1 | 5.1 | 4.845 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4734A
|
![]() |
Active | 1 | 5.6 | 5.32 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4735A
|
![]() |
Active | 1 | 6.2 | 5.89 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4736A
|
![]() |
Active | 1 | 6.8 | 6.46 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4737A
|
![]() |
Active | 1 | 7.5 | 7.125 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4738A
|
![]() |
Active | 1 | 8.2 | 7.79 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4739A
|
![]() |
Active | 1 | 9.1 | 8.645 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4740A
|
![]() |
Active | 1 | 10 | 9.5 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4741A
|
![]() |
Active | 1 | 11 | 10.45 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4742A
|
![]() |
Active | 1 | 12 | 11.4 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4743A
|
![]() |
Active | 1 | 13 | 12.35 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4744A
|
![]() |
Active | 1 | 15 | 14.25 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4745A
|
![]() |
Active | 1 | 16 | 15.2 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4746A
|
![]() |
Active | 1 | 18 | 17.1 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4747A
|
![]() |
Active | 1 | 20 | 19 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4748A
|
![]() |
Active | 1 | 22 | 20.9 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4749A
|
![]() |
Active | 1 | 24 | 22.8 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4750A
|
![]() |
Active | 1 | 27 | 25.65 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4751A
|
![]() |
Active | 1 | 30 | 28.5 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4752A
|
![]() |
Active | 1 | 33 | 31.35 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4753A
|
![]() |
Active | 1 | 36 | 34.2 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4754A
|
![]() |
Active | 1 | 39 | 37.05 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4755A
|
![]() |
Active | 1 | 43 | 40.85 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4756A
|
![]() |
Active | 1 | 47 | 44.65 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4757A
|
![]() |
Active | 1 | 51 | 48.45 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4758A
|
![]() |
Active | 1 | 56 | 53.2 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4759A
|
![]() |
Active | 1 | 62 | 58.9 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4760A
|
![]() |
Active | 1 | 68 | 64.6 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4761A
|
![]() |
Active | 1 | 75 | 71.25 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4762A
|
![]() |
Active | 1 | 82 | 77.9 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4763A
|
![]() |
Active | 1 | 91 | 86.45 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
SMA4764A
|
![]() |
Active | 1 | 100 | 95 | null | - | 5 | 150°C | SMA (DO-214AC) | ||
|
BZT52C2V4
|
![]() |
Active | 0.41 | 2.4 | 2.28 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C2V7
|
![]() |
Active | 0.41 | 2.7 | 2.5 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C3V0
|
![]() |
Active | 0.41 | 3 | 2.8 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C3V3
|
![]() |
Active | 0.41 | 3.3 | 3.1 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C3V6
|
![]() |
Active | 0.41 | 3.6 | 3.4 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C3V9
|
![]() |
Active | 0.41 | 3.9 | 3.7 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C4V3
|
![]() |
Active | 0.41 | 4.3 | 4 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C4V7
|
![]() |
Active | 0.41 | 4.7 | 4.4 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C5V1
|
![]() |
Active | 0.41 | 5.1 | 4.8 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C5V6
|
![]() |
Active | 0.41 | 5.6 | 5.2 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C6V2
|
![]() |
Active | 0.41 | 6.2 | 5.8 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C6V8
|
![]() |
Active | 0.41 | 6.8 | 6.4 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C7V5
|
![]() |
Active | 0.41 | 7.5 | 7 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C8V2
|
![]() |
Active | 0.41 | 8.2 | 7.7 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C9V1
|
![]() |
Active | 0.41 | 9.1 | 8.5 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C10
|
![]() |
Active | 0.41 | 10 | 9.4 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C11
|
![]() |
Active | 0.41 | 11 | 10.4 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C12
|
![]() |
Active | 0.41 | 12 | 11.4 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C13
|
![]() |
Active | 0.41 | 13 | 12.4 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C15
|
![]() |
Active | 0.41 | 15 | 13.8 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C16
|
![]() |
Active | 0.41 | 16 | 15.3 | 17.1 | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C18
|
![]() |
Active | 0.41 | 18 | 16.8 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C20
|
![]() |
Active | 0.41 | 20 | 18.8 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C22
|
![]() |
Active | 0.41 | 22 | 20.8 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C24
|
![]() |
Active | 0.41 | 24 | 22.8 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C27
|
![]() |
Active | 0.41 | 27 | 25.1 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C30
|
![]() |
Active | 0.41 | 30 | 28 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C33
|
![]() |
Active | 0.41 | 33 | 31 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C36
|
![]() |
Active | 0.41 | 36 | 34 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C39
|
![]() |
Active | 0.41 | 39 | 37 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C43
|
![]() |
Active | 0.41 | 43 | 40 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C47
|
![]() |
Active | 0.41 | 47 | 44 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C51
|
![]() |
Active | 0.41 | 51 | 48 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C56
|
![]() |
Active | 0.41 | 56 | 52 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C62
|
![]() |
Active | 0.41 | 62 | 58 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C68
|
![]() |
Active | 0.41 | 68 | 64 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
BZT52C75
|
![]() |
Active | 0.41 | 75 | 70 | null | - | 5 | 150°C | SOD-123 (0.41W) | ||
|
MM3Z2V4T1
|
![]() |
Active | 0.2 | 2.4 | 2.28 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z2V7T1
|
![]() |
Active | 0.2 | 2.7 | 2.57 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z3V0T1
|
![]() |
Active | 0.2 | 3 | 2.85 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z3V3T1
|
![]() |
Active | 0.2 | 3.3 | 3.14 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z3V6T1
|
![]() |
Active | 0.2 | 3.6 | 3.42 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z3V9T1
|
![]() |
Active | 0.2 | 3.9 | 3.71 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z4V3T1
|
![]() |
Active | 0.2 | 4.3 | 4.09 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z4V7T1
|
![]() |
Active | 0.2 | 4.7 | 4.47 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z5V1T1
|
![]() |
Active | 0.2 | 5.1 | 4.85 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z5V6T1
|
![]() |
Active | 0.2 | 5.6 | 5.32 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z6V2T1
|
![]() |
Active | 0.2 | 6.2 | 5.89 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z6V8T1
|
![]() |
Active | 0.2 | 6.8 | 6.46 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z7V5T1
|
![]() |
Active | 0.2 | 7.5 | 7.11 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z8V2T1
|
![]() |
Active | 0.2 | 8.2 | 7.79 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z9V1T1
|
![]() |
Active | 0.2 | 9.1 | 8.65 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z10VT1
|
![]() |
Active | 0.2 | 10 | 9.5 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z11VT1
|
![]() |
Active | 0.2 | 11 | 10.45 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z12VT1
|
![]() |
Active | 0.2 | 12 | 11.4 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z13VT1
|
![]() |
Active | 0.2 | 13 | 12.35 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z15VT1
|
![]() |
Active | 0.2 | 15 | 14.25 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z16VT1
|
![]() |
Active | 0.2 | 16 | 15.2 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z18VT1
|
![]() |
Active | 0.2 | 18 | 17.1 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z20VT1
|
![]() |
Active | 0.2 | 20 | 19 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z22VT1
|
![]() |
Active | 0.2 | 22 | 20.9 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z24VT1
|
![]() |
Active | 0.2 | 24 | 22.8 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z27VT1
|
![]() |
Active | 0.2 | 27 | 25.65 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z30VT1
|
![]() |
Active | 0.2 | 30 | 28.5 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z33VT1
|
![]() |
Active | 0.2 | 33 | 31.35 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z36VT1
|
![]() |
Active | 0.2 | 36 | 34.2 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z39VT1
|
![]() |
Active | 0.2 | 39 | 37.05 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z43VT1
|
![]() |
Active | 0.2 | 43 | 40.85 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z47VT1
|
![]() |
Active | 0.2 | 47 | 44.65 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z51VT1
|
![]() |
Active | 0.2 | 51 | 48.45 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z56VT1
|
![]() |
Active | 0.2 | 56 | 53.2 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z62VT1
|
![]() |
Active | 0.2 | 62 | 58.9 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z68VT1
|
![]() |
Active | 0.2 | 68 | 64.6 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM3Z75VT1
|
![]() |
Active | 0.2 | 75 | 71.25 | null | - | 5 | 150°C | SOD-323 (0.2W) | ||
|
MM5Z2V4
|
![]() |
Active | 0.2 | 2.4 | 2.28 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z2V7
|
![]() |
Active | 0.2 | 2.7 | 2.5 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z3V0
|
![]() |
Active | 0.2 | 3 | 2.8 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z3V3
|
![]() |
Active | 0.2 | 3.3 | 3.1 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z3V6
|
![]() |
Active | 0.2 | 3.6 | 3.4 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z3V9
|
![]() |
Active | 0.2 | 3.9 | 3.7 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z4V3
|
![]() |
Active | 0.2 | 4.3 | 4 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z4V7
|
![]() |
Active | 0.2 | 4.7 | 4.4 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z5V1
|
![]() |
Active | 0.2 | 5.1 | 4.8 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z5V6
|
![]() |
Active | 0.2 | 5.6 | 5.2 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z6V2
|
![]() |
Active | 0.2 | 6.2 | 5.8 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z6V8
|
![]() |
Active | 0.2 | 6.8 | 6.4 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z7V5
|
![]() |
Active | 0.2 | 7.5 | 7 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z8V2
|
![]() |
Active | 0.2 | 8.2 | 7.7 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z9V1
|
![]() |
Active | 0.2 | 9.1 | 8.5 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z10V
|
![]() |
Active | 0.2 | 10 | 9.4 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z11V
|
![]() |
Active | 0.2 | 11 | 10.4 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z12V
|
![]() |
Active | 0.2 | 12 | 11.4 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z13V
|
![]() |
Active | 0.2 | 13 | 12.4 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z15V
|
![]() |
Active | 0.2 | 15 | 13.8 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z16V
|
![]() |
Active | 0.2 | 16 | 15.3 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z18V
|
![]() |
Active | 0.2 | 18 | 16.8 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z20V
|
![]() |
Active | 0.2 | 20 | 18.8 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z22V
|
![]() |
Active | 0.2 | 22 | 20.8 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z24V
|
![]() |
Active | 0.2 | 24 | 22.8 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z27V
|
![]() |
Active | 0.2 | 27 | 25.1 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z30V
|
![]() |
Active | 0.2 | 30 | 28 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z33V
|
![]() |
Active | 0.2 | 33 | 31 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z36V
|
![]() |
Active | 0.2 | 36 | 34 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z39V
|
![]() |
Active | 0.2 | 39 | 37 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z43V
|
![]() |
Active | 0.2 | 43 | 40 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z47V
|
![]() |
Active | 0.2 | 47 | 44 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z51V
|
![]() |
Active | 0.2 | 51 | 48 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z56V
|
![]() |
Active | 0.2 | 56 | 52 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z62V
|
![]() |
Active | 0.2 | 62 | 58 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z68V
|
![]() |
Active | 0.2 | 68 | 64 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
MM5Z75V
|
![]() |
Active | 0.2 | 75 | 70 | null | - | 5 | 150°C | SOD-523 (0.2W) | ||
|
BZX84C2V4
|
![]() |
Active | 0.25 | 2.4 | 2.2 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C2V7
|
![]() |
Active | 0.25 | 2.7 | 2.5 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C3V0
|
![]() |
Active | 0.25 | 3 | 2.8 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C3V3
|
![]() |
Active | 0.25 | 3.3 | 3.1 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C3V6
|
![]() |
Active | 0.25 | 3.6 | 3.4 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C3V9
|
![]() |
Active | 0.25 | 3.9 | 3.7 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C4V3
|
![]() |
Active | 0.25 | 4.3 | 4 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C4V7
|
![]() |
Active | 0.25 | 4.7 | 4.4 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C5V1
|
![]() |
Active | 0.25 | 5.1 | 4.8 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C5V6
|
![]() |
Active | 0.25 | 5.6 | 5.2 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C6V2
|
![]() |
Active | 0.25 | 6.2 | 5.8 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C6V8
|
![]() |
Active | 0.25 | 6.8 | 6.4 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C7V5
|
![]() |
Active | 0.25 | 7.5 | 7 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C8V2
|
![]() |
Active | 0.25 | 8.2 | 7.7 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C9V1
|
![]() |
Active | 0.25 | 9.1 | 8.5 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C10
|
![]() |
Active | 0.25 | 10 | 9.4 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C11
|
![]() |
Active | 0.25 | 11 | 10.4 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C12
|
![]() |
Active | 0.25 | 12 | 11.4 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C13
|
![]() |
Active | 0.25 | 13 | 12.4 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C15
|
![]() |
Active | 0.25 | 15 | 13.8 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C16
|
![]() |
Active | 0.25 | 16 | 15.3 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C18
|
![]() |
Active | 0.25 | 18 | 16.8 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C20
|
![]() |
Active | 0.25 | 20 | 18.8 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C22
|
![]() |
Active | 0.25 | 22 | 20.8 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C24
|
![]() |
Active | 0.25 | 24 | 22.8 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C27
|
![]() |
Active | 0.25 | 27 | 25.1 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C30
|
![]() |
Active | 0.25 | 30 | 28 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C33
|
![]() |
Active | 0.25 | 33 | 31 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C36
|
![]() |
Active | 0.25 | 36 | 34 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C39
|
![]() |
Active | 0.25 | 39 | 37 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C43
|
![]() |
Active | 0.25 | 43 | 40 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C47
|
![]() |
Active | 0.25 | 47 | 44 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C51
|
![]() |
Active | 0.25 | 51 | 48 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C56
|
![]() |
Active | 0.25 | 56 | 52 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C62
|
![]() |
Active | 0.25 | 62 | 58 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C68
|
![]() |
Active | 0.25 | 68 | 64 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
BZX84C75
|
![]() |
Active | 0.25 | 75 | 70 | null | 1.5 | 5 | 150°C | SOT-23 (0.25W) | ||
|
1N5221B
|
![]() |
Active | 0.5 | 2.4 | 2.28 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5222B
|
![]() |
Active | 0.5 | 2.5 | 2.375 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5223B
|
![]() |
Active | 0.5 | 2.7 | 2.565 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5224B
|
![]() |
Active | 0.5 | 2.8 | 2.66 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5225B
|
![]() |
Active | 0.5 | 3 | 2.85 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5226B
|
![]() |
Active | 0.5 | 3.3 | 3.135 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5227B
|
![]() |
Active | 0.5 | 3.6 | 3.42 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5228B
|
![]() |
Active | 0.5 | 3.9 | 3.705 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5229B
|
![]() |
Active | 0.5 | 4.3 | 4.085 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5230B
|
![]() |
Active | 0.5 | 4.7 | 4.465 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5231B
|
![]() |
Active | 0.5 | 5.1 | 4.845 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5232B
|
![]() |
Active | 0.5 | 5.6 | 5.32 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5233B
|
![]() |
Active | 0.5 | 6 | 5.7 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5234B
|
![]() |
Active | 0.5 | 6.2 | 5.89 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5235B
|
![]() |
Active | 0.5 | 6.8 | 6.46 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5236B
|
![]() |
Active | 0.5 | 7.5 | 7.125 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5237B
|
![]() |
Active | 0.5 | 8.2 | 7.79 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5238B
|
![]() |
Active | 0.5 | 8.7 | 8.265 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5239B
|
![]() |
Active | 0.5 | 9.1 | 8.645 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5240B
|
![]() |
Active | 0.5 | 10 | 9.5 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5241B
|
![]() |
Active | 0.5 | 11 | 10.45 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5242B
|
![]() |
Active | 0.5 | 12 | 11.4 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5243B
|
![]() |
Active | 0.5 | 13 | 12.35 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5244B
|
![]() |
Active | 0.5 | 14 | 13.3 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5245B
|
![]() |
Active | 0.5 | 15 | 14.25 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5246B
|
![]() |
Active | 0.5 | 16 | 15.2 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5247B
|
![]() |
Active | 0.5 | 17 | 16.15 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5248B
|
![]() |
Active | 0.5 | 18 | 17.1 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5249B
|
![]() |
Active | 0.5 | 19 | 18.05 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5250B
|
![]() |
Active | 0.5 | 20 | 19 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5251B
|
![]() |
Active | 0.5 | 22 | 20.9 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5252B
|
![]() |
Active | 0.5 | 24 | 22.8 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5253B
|
![]() |
Active | 0.5 | 25 | 23.75 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5254B
|
![]() |
Active | 0.5 | 27 | 25.65 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5255B
|
![]() |
Active | 0.5 | 28 | 26.6 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5256B
|
![]() |
Active | 0.5 | 30 | 28.5 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5257B
|
![]() |
Active | 0.5 | 33 | 31.35 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5258B
|
![]() |
Active | 0.5 | 36 | 34.2 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5259B
|
![]() |
Active | 0.5 | 39 | 37.05 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5260B
|
![]() |
Active | 0.5 | 43 | 40.85 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5261B
|
![]() |
Active | 0.5 | 47 | 44.65 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5262B
|
![]() |
Active | 0.5 | 51 | 48.45 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5263B
|
![]() |
Active | 0.5 | 56 | 53.2 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5264B
|
![]() |
Active | 0.5 | 60 | 57 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5265B
|
![]() |
Active | 0.5 | 62 | 58.9 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5266B
|
![]() |
Active | 0.5 | 68 | 64.6 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
1N5267B
|
![]() |
Active | 0.5 | 75 | 71.25 | null | 1.1 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C2V4
|
![]() |
Active | 0.5 | 2.4 | 2.28 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C2V7
|
![]() |
Active | 0.5 | 2.7 | 2.5 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C3V0
|
![]() |
Active | 0.5 | 3 | 2.8 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C3V3
|
![]() |
Active | 0.5 | 3.3 | 3.1 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C3V6
|
![]() |
Active | 0.5 | 3.6 | 3.4 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C3V9
|
![]() |
Active | 0.5 | 3.9 | 3.7 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C4V3
|
![]() |
Active | 0.5 | 4.3 | 4 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C4V7
|
![]() |
Active | 0.5 | 4.7 | 4.4 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C5V1
|
![]() |
Active | 0.5 | 5.1 | 4.8 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C5V6
|
![]() |
Active | 0.5 | 5.6 | 5.2 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C6V2
|
![]() |
Active | 0.5 | 6.2 | 5.8 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C6V8
|
![]() |
Active | 0.5 | 6.8 | 6.4 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C7V5
|
![]() |
Active | 0.5 | 7.5 | 7 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C8V2
|
![]() |
Active | 0.5 | 8.2 | 7.7 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C9V1
|
![]() |
Active | 0.5 | 9.1 | 8.5 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C10
|
![]() |
Active | 0.5 | 10 | 9.4 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C11
|
![]() |
Active | 0.5 | 11 | 10.4 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C12
|
![]() |
Active | 0.5 | 12 | 11.4 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C13
|
![]() |
Active | 0.5 | 13 | 12.4 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C15
|
![]() |
Active | 0.5 | 15 | 13.8 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C16
|
![]() |
Active | 0.5 | 16 | 15.3 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C18
|
![]() |
Active | 0.5 | 18 | 16.8 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C20
|
![]() |
Active | 0.5 | 20 | 18.8 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C22
|
![]() |
Active | 0.5 | 22 | 20.8 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C24
|
![]() |
Active | 0.5 | 24 | 22.8 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C27
|
![]() |
Active | 0.5 | 27 | 25.1 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C30
|
![]() |
Active | 0.5 | 30 | 28 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C33
|
![]() |
Active | 0.5 | 33 | 31 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C36
|
![]() |
Active | 0.5 | 36 | 34 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C39
|
![]() |
Active | 0.5 | 39 | 37 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C43
|
![]() |
Active | 0.5 | 43 | 40 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C47
|
![]() |
Active | 0.5 | 47 | 44 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C51
|
![]() |
Active | 0.5 | 51 | 48 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C56
|
![]() |
Active | 0.5 | 56 | 52 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C62
|
![]() |
Active | 0.5 | 62 | 58 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C68
|
![]() |
Active | 0.5 | 68 | 64 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
BZX55C75
|
![]() |
Active | 0.5 | 75 | 70 | null | 1.5 | 5 | 175°C | DO-35 (Glass) | ||
|
1N4728A
|
![]() |
Active | 1 | 3.3 | 3.1 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4729A
|
![]() |
Active | 1 | 3.6 | 3.4 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4730A
|
![]() |
Active | 1 | 3.9 | 3.7 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4731A
|
![]() |
Active | 1 | 4.3 | 4 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4732A
|
![]() |
Active | 1 | 4.7 | 4.4 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4733A
|
![]() |
Active | 1 | 5.1 | 4.8 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4734A
|
![]() |
Active | 1 | 5.6 | 5.2 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4735A
|
![]() |
Active | 1 | 6.2 | 5.8 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4736A
|
![]() |
Active | 1 | 6.8 | 6.4 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4737A
|
![]() |
Active | 1 | 7.5 | 7 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4738A
|
![]() |
Active | 1 | 8.2 | 7.7 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4739A
|
![]() |
Active | 1 | 9.1 | 8.5 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4740A
|
![]() |
Active | 1 | 10 | 9.4 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4741A
|
![]() |
Active | 1 | 11 | 10.4 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4742A
|
![]() |
Active | 1 | 12 | 11.4 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4743A
|
![]() |
Active | 1 | 13 | 12.4 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4744A
|
![]() |
Active | 1 | 15 | 13.8 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4745A
|
![]() |
Active | 1 | 16 | 15.3 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4746A
|
![]() |
Active | 1 | 18 | 16.8 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4747A
|
![]() |
Active | 1 | 20 | 18.8 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4748A
|
![]() |
Active | 1 | 22 | 20.8 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4749A
|
![]() |
Active | 1 | 24 | 22.8 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4750A
|
![]() |
Active | 1 | 27 | 25.1 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4751A
|
![]() |
Active | 1 | 30 | 28 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4752A
|
![]() |
Active | 1 | 33 | 31 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4753A
|
![]() |
Active | 1 | 36 | 34 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4754A
|
![]() |
Active | 1 | 39 | 37 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4755A
|
![]() |
Active | 1 | 43 | 40 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4756A
|
![]() |
Active | 1 | 47 | 44 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4757A
|
![]() |
Active | 1 | 51 | 48 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4758A
|
![]() |
Active | 1 | 56 | 52 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4759A
|
![]() |
Active | 1 | 62 | 58 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4760A
|
![]() |
Active | 1 | 68 | 64 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4761A
|
![]() |
Active | 1 | 75 | 70 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4762A
|
![]() |
Active | 1 | 82 | 77.9 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4763A
|
![]() |
Active | 1 | 91 | 86.45 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
1N4764A
|
![]() |
Active | 1 | 100 | 95 | null | 1.2 | 5 | 200°C | DO-41 (Glass) | ||
|
BZX85C2V7
|
![]() |
Active | 1.3 | 2.7 | 2.5 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C3V0
|
![]() |
Active | 1.3 | 3 | 2.8 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C3V3
|
![]() |
Active | 1.3 | 3.3 | 3.1 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C3V6
|
![]() |
Active | 1.3 | 3.6 | 3.4 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C3V9
|
![]() |
Active | 1.3 | 3.9 | 3.7 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C4V3
|
![]() |
Active | 1.3 | 4.3 | 4 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C4V7
|
![]() |
Active | 1.3 | 4.7 | 4.4 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C5V1
|
![]() |
Active | 1.3 | 5.1 | 4.8 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C5V6
|
![]() |
Active | 1.3 | 5.6 | 5.2 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C6V2
|
![]() |
Active | 1.3 | 6.2 | 5.8 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C6V8
|
![]() |
Active | 1.3 | 6.8 | 6.4 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C7V5
|
![]() |
Active | 1.3 | 7.5 | 7 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C8V2
|
![]() |
Active | 1.3 | 8.2 | 7.7 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C9V1
|
![]() |
Active | 1.3 | 9.1 | 8.5 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C10
|
![]() |
Active | 1.3 | 10 | 9.4 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C11
|
![]() |
Active | 1.3 | 11 | 10.4 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C12
|
![]() |
Active | 1.3 | 12 | 11.4 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C13
|
![]() |
Active | 1.3 | 13 | 12.4 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C15
|
![]() |
Active | 1.3 | 15 | 13.8 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C16
|
![]() |
Active | 1.3 | 16 | 15.3 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C18
|
![]() |
Active | 1.3 | 18 | 16.8 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C20
|
![]() |
Active | 1.3 | 20 | 18.8 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C22
|
![]() |
Active | 1.3 | 22 | 20.8 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C24
|
![]() |
Active | 1.3 | 24 | 22.8 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C27
|
![]() |
Active | 1.3 | 27 | 25.1 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C30
|
![]() |
Active | 1.3 | 30 | 28 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C33
|
![]() |
Active | 1.3 | 33 | 31 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C36
|
![]() |
Active | 1.3 | 36 | 34 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C39
|
![]() |
Active | 1.3 | 39 | 37 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C43
|
![]() |
Active | 1.3 | 43 | 40 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C47
|
![]() |
Active | 1.3 | 47 | 44 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C51
|
![]() |
Active | 1.3 | 51 | 48 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C56
|
![]() |
Active | 1.3 | 56 | 52 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C62
|
![]() |
Active | 1.3 | 62 | 58 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C68
|
![]() |
Active | 1.3 | 68 | 64 | null | 1.5 | 5 | 175°C | DO-41 (Glass) | ||
|
BZX85C75
|
![]() |
Active | 1.3 | 75 | 70 | null | 1.5 | 5 | 175°C | DO-41 (Glass) |
