PART NO. | Picture | Product Status | VRRM (VPK) | Current (A) (Per pkg) | IF (A) (Per diode) | IFSM Max (A) | VF @25°C (V) | Configuration | IR @25°C (μA) | IR @150°C (mA) | TJ (°C) | Package | CAD模型 | 電路圖 |
|
M1PIA50-060
|
![]() |
Active | 600 | 50 | 50 | 700 | 1.1 | 4 | 10 | 10 | -40°C to +150°C | SOT-227H | ||
|
DAR3PV086-160W
|
![]() |
Active | 1600 | 86 | 86 | 595 | 1.5 | 5 | 40 | 1.5 | -40°C to +150°C | DAR3PV-28.5mm | ||
|
DAR3PY086-160W
|
|
Active | 1600 | 86 | 86 | 595 | 1.5 | 7 | 40 | 1.5 | -40°C to +150°C | DAR3PY-12mm | ||
|
DAR3PX086-160W
|
![]() |
Active | 1600 | 86 | 86 | 595 | 1.5 | 7 | 40 | 1.5 | -40°C to +150°C | DAR3PX-17mm |
