PART NO. | Picture | Product Status | VRRM (VPK) | Current (A) (Per pkg) | IF @Tc(A) (Per diode) | @Tc (°C) | IFSM Max (A) | VF @25°C (V) | VF @125°C (V) | Configuration | IR @25°C (mA) | IR @125°C (mA) | TJ (°C) | Package | CAD模型 | 電路圖 |
|
MBRI2X30-045A
|
![]() |
Active | 45 | 60 | 30 | 110 | 500 | 0.7 | 0.66 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X30-060A
|
![]() |
Active | 60 | 60 | 30 | 110 | 500 | 0.75 | 0.7 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X30-080A
|
![]() |
Active | 80 | 60 | 30 | 110 | 500 | 0.84 | 0.75 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X30-100A
|
![]() |
Active | 100 | 60 | 30 | 110 | 500 | 0.84 | 0.75 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X50-045A
|
![]() |
Active | 45 | 100 | 50 | 110 | 750 | 0.7 | 0.62 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X50-060A
|
![]() |
Active | 60 | 100 | 50 | 110 | 750 | 0.75 | 0.65 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X50-080A
|
![]() |
Active | 80 | 100 | 50 | 110 | 750 | 0.84 | 0.67 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X50-100A
|
![]() |
Active | 100 | 100 | 50 | 110 | 750 | 0.84 | 0.7 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X50-120A
|
![]() |
Active | 120 | 100 | 50 | 110 | 750 | 0.88 | 0.75 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X50-150A
|
![]() |
Active | 150 | 100 | 50 | 110 | 750 | 0.88 | 0.75 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X50-180A
|
![]() |
Active | 180 | 100 | 50 | 110 | 750 | 0.92 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X50-200A
|
![]() |
Active | 200 | 100 | 50 | 110 | 750 | 0.92 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X51-045A
|
![]() |
Active | 45 | 100 | 50 | 110 | 700 | 0.7 | 0.62 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X51-060A
|
![]() |
Active | 60 | 100 | 50 | 110 | 700 | 0.75 | 0.65 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X51-080A
|
![]() |
Active | 80 | 100 | 50 | 110 | 700 | 0.84 | 0.67 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X51-100A
|
![]() |
Active | 100 | 100 | 50 | 110 | 700 | 0.84 | 0.7 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X51-120A
|
![]() |
Active | 120 | 100 | 50 | 110 | 700 | 0.88 | 0.75 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X51-150A
|
![]() |
Active | 150 | 100 | 50 | 110 | 700 | 0.88 | 0.75 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X51-180A
|
![]() |
Active | 180 | 100 | 50 | 110 | 700 | 0.92 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X51-200A
|
![]() |
Active | 200 | 100 | 50 | 110 | 700 | 0.92 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X60-045A
|
![]() |
Active | 45 | 120 | 60 | 110 | 850 | 0.7 | 0.64 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X60-060A
|
![]() |
Active | 60 | 120 | 60 | 110 | 850 | 0.75 | 0.7 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X60-080A
|
![]() |
Active | 80 | 120 | 60 | 110 | 850 | 0.84 | 0.73 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X60-100A
|
![]() |
Active | 100 | 120 | 60 | 110 | 850 | 0.84 | 0.74 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X60-120A
|
![]() |
Active | 120 | 120 | 60 | 110 | 850 | 0.88 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X60-150A
|
![]() |
Active | 150 | 120 | 60 | 110 | 850 | 0.88 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X60-180A
|
![]() |
Active | 180 | 120 | 60 | 110 | 850 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X60-200A
|
![]() |
Active | 200 | 120 | 60 | 110 | 850 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X61-045A
|
![]() |
Active | 45 | 120 | 60 | 110 | 800 | 0.7 | 0.64 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X61-060A
|
![]() |
Active | 60 | 120 | 60 | 110 | 800 | 0.75 | 0.7 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X61-080A
|
![]() |
Active | 80 | 120 | 60 | 110 | 800 | 0.84 | 0.73 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X61-100A
|
![]() |
Active | 100 | 120 | 60 | 110 | 800 | 0.84 | 0.74 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X61-120A
|
![]() |
Active | 120 | 120 | 60 | 110 | 800 | 0.88 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X61-150A
|
![]() |
Active | 150 | 120 | 60 | 110 | 800 | 0.88 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X61-180A
|
![]() |
Active | 180 | 120 | 60 | 110 | 800 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X61-200A
|
![]() |
Active | 200 | 120 | 60 | 110 | 800 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X80-045A
|
![]() |
Active | 45 | 160 | 80 | 110 | 900 | 0.7 | 0.62 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X80-060A
|
![]() |
Active | 60 | 160 | 80 | 110 | 900 | 0.75 | 0.7 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X80-080A
|
![]() |
Active | 80 | 160 | 80 | 110 | 900 | 0.84 | 0.73 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X80-100A
|
![]() |
Active | 100 | 160 | 80 | 110 | 900 | 0.84 | 0.75 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X80-120A
|
![]() |
Active | 120 | 160 | 80 | 110 | 900 | 0.88 | 0.76 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X80-150A
|
![]() |
Active | 150 | 160 | 80 | 110 | 900 | 0.88 | 0.76 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X80-180A
|
![]() |
Active | 180 | 160 | 80 | 110 | 900 | 0.92 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X80-200A
|
![]() |
Active | 200 | 160 | 80 | 110 | 900 | 0.92 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X100-045A
|
![]() |
Active | 45 | 200 | 100 | 110 | 1400 | 0.7 | 0.63 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X100-060A
|
![]() |
Active | 60 | 200 | 100 | 110 | 1400 | 0.75 | 0.7 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X100-080A
|
![]() |
Active | 80 | 200 | 100 | 110 | 1400 | 0.84 | 0.73 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X100-100A
|
![]() |
Active | 100 | 200 | 100 | 110 | 1400 | 0.84 | 0.75 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X100-120A
|
![]() |
Active | 120 | 200 | 100 | 110 | 1400 | 0.88 | 0.77 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X100-150A
|
![]() |
Active | 150 | 200 | 100 | 110 | 1400 | 0.88 | 0.77 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X100-170A
|
![]() |
Active | 170 | 200 | 100 | 110 | 1400 | 0.85 | 0.77 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X100-180A
|
![]() |
Active | 180 | 200 | 100 | 110 | 1400 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X100-200A
|
![]() |
Active | 200 | 200 | 100 | 110 | 1400 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X120-045A
|
![]() |
Active | 45 | 240 | 120 | 110 | 1800 | 0.7 | 0.64 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X120-060A
|
![]() |
Active | 60 | 240 | 120 | 110 | 1800 | 0.75 | 0.7 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X120-080A
|
![]() |
Active | 80 | 240 | 120 | 110 | 1800 | 0.84 | 0.73 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X120-100A
|
![]() |
Active | 100 | 240 | 120 | 110 | 1800 | 0.84 | 0.75 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X120-120A
|
![]() |
Active | 120 | 240 | 120 | 110 | 1800 | 0.88 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X120-150A
|
![]() |
Active | 150 | 240 | 120 | 110 | 1800 | 0.88 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X120-180A
|
![]() |
Active | 180 | 240 | 120 | 110 | 1800 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X120-200A
|
![]() |
Active | 200 | 240 | 120 | 110 | 1800 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X121-045A
|
![]() |
Active | 45 | 240 | 120 | 110 | 1500 | 0.7 | 0.64 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X121-060A
|
![]() |
Active | 60 | 240 | 120 | 110 | 1500 | 0.75 | 0.7 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X121-080A
|
![]() |
Active | 80 | 240 | 120 | 110 | 1500 | 0.84 | 0.73 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X121-100A
|
![]() |
Active | 100 | 240 | 120 | 110 | 1800 | 0.84 | 0.75 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X121-120A
|
![]() |
Active | 120 | 240 | 120 | 110 | 1500 | 0.88 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X121-150A
|
![]() |
Active | 150 | 240 | 120 | 110 | 1500 | 0.88 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X121-180A
|
![]() |
Active | 180 | 240 | 120 | 110 | 1500 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X121-200A
|
![]() |
Active | 200 | 240 | 120 | 110 | 1500 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X160-080A
|
![]() |
Active | 80 | 320 | 160 | 110 | 2000 | 0.84 | 0.73 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X160-100A
|
![]() |
Active | 100 | 320 | 160 | 110 | 2000 | 0.84 | 0.75 | Dual | 1 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X161-100A
|
![]() |
Active | 100 | 320 | 160 | 110 | 1800 | 0.86 | 0.78 | Dual | 3 | 15 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X160-120A
|
![]() |
Active | 120 | 320 | 160 | 110 | 2000 | 0.88 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X160-150A
|
![]() |
Active | 150 | 320 | 160 | 110 | 2000 | 0.88 | 0.8 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X160-180A
|
![]() |
Active | 180 | 320 | 160 | 110 | 2000 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X160-200A
|
![]() |
Active | 200 | 320 | 160 | 110 | 2000 | 0.92 | 0.82 | Dual | 3 | 20 | -40°C to +150°C | SOT-227 (Isolated) | ||
|
MBRI2X160-100N
|
![]() |
Active | 100 | 320 | 160 | 110 | 2000 | 0.84 | 0.75 | Common Cathode | 1 | 20 | -40°C to +150°C | SOT-227 (Not Insulated) | ||
|
MBRTT20020
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20020R
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20020A
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20020AR
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20020D
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20020AD
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20020ADR
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20030
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20030R
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20030A
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20030AR
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20030D
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20030AD
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20030ADR
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20035
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20035R
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20035A
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20035AR
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20035D
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20035AD
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20035ADR
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20040
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20040R
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20040A
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20040AR
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20040D
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20040AD
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20040ADR
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20045
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20045R
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20045A
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20045AR
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20045D
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20045AD
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20045ADR
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | 0.64 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20060
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | 0.7 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20060R
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | 0.7 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20060A
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | 0.7 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20060AR
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | 0.7 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20060D
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | 0.7 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20060AD
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | 0.7 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT20060ADR
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | 0.7 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200100
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200100R
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200100A
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200100AR
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200100D
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200100AD
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200100ADR
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200150
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | 0.78 | Common Cathode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200150R
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | 0.78 | Common Anode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200150A
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | 0.78 | A Common Cathode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200150AR
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | 0.78 | AR Common Anode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200150D
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | 0.78 | Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200150AD
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | 0.78 | AD Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200150ADR
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | 0.78 | ADR Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200200
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | 0.82 | Common Cathode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200200R
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | 0.82 | Common Anode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200200A
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | 0.82 | A Common Cathode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200200AR
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | 0.82 | AR Common Anode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200200D
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | 0.82 | Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200200AD
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | 0.82 | AD Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT200200ADR
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | 0.82 | ADR Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30020
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30020R
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30020A
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30020AR
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30020D
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30020AD
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30020ADR
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30030
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30030R
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30030A
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30030AR
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30030D
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30030AD
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30030ADR
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30035
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30035R
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30035A
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30035AR
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30035D
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30035AD
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30035ADR
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30040
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30040R
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30040A
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30040AR
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30040D
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30040AD
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30040ADR
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30045
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30045R
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30045A
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30045AR
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30045D
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30045AD
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30045ADR
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | 0.64 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30060
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | 0.7 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30060R
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | 0.7 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30060A
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | 0.7 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30060AR
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | 0.7 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30060D
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | 0.7 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30060AD
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | 0.7 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT30060ADR
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | 0.7 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300100
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | 0.74 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300100R
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | 0.74 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300100A
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | 0.74 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300100AR
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | 0.74 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300100D
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | 0.74 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300100AD
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | 0.74 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300100ADR
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | 0.74 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300150
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | Common Cathode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300150R
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | Common Anode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300150A
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | A Common Cathode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300150AR
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | AR Common Anode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300150D
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300150AD
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | AD Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300150ADR
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | ADR Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300200
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | Common Cathode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300200R
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | Common Anode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300200A
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | A Common Cathode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300200AR
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | AR Common Anode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300200D
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300200AD
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | AD Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT300200ADR
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | ADR Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40020
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40020R
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40020A
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | A Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40020AR
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | AR Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40020D
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40020AD
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | AD Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40020ADR
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | ADR Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40030
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40030R
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40030A
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | A Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40030AR
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | AR Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40030D
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40030AD
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | AD Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40030ADR
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | ADR Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40035
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40035R
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40035A
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | A Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40035AR
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | AR Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40035D
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40035AD
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | AD Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40035ADR
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | ADR Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40040
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40040R
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40040A
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | A Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40040AR
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | AR Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40040D
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40040AD
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | AD Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40040ADR
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | ADR Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40045
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40045R
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40045A
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | A Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40045AR
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | AR Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40045D
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40045AD
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | AD Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40045ADR
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | 0.64 | ADR Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40060
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | 0.7 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40060R
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | 0.7 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40060A
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | 0.7 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40060AR
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | 0.7 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40060D
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | 0.7 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40060AD
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | 0.7 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT40060ADR
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | 0.7 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400100
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | 0.74 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400100R
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | 0.74 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400100A
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | 0.74 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400100AR
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | 0.74 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400100D
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | 0.74 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400100AD
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | 0.74 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400100ADR
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | 0.74 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400150
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | 0.8 | Common Cathode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400150R
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | 0.8 | Common Anode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400150A
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | 0.8 | A Common Cathode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400150AR
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | 0.8 | AR Common Anode | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400150D
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | 0.8 | Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400150AD
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | 0.8 | AD Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400150ADR
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | 0.8 | ADR Doubler | 3 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400200
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | 0.82 | Common Cathode | 3 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400200R
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | 0.82 | Common Anode | 3 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400200A
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | 0.82 | A Common Cathode | 3 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400200AR
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | 0.82 | AR Common Anode | 3 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400200D
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | 0.82 | Doubler | 3 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400200AD
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | 0.82 | AD Doubler | 3 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT400200ADR
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | 0.82 | ADR Doubler | 3 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60020
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60020R
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60020A
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | A Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60020AR
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | AR Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60020D
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60020AD
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | AD Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60020ADR
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | ADR Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60030
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60030R
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60030A
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | A Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60030AR
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | AR Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60030D
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60030AD
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | AD Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60030ADR
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | ADR Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60035
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60035R
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60035A
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | A Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60035AR
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | AR Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60035D
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60035AD
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | AD Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60035ADR
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | ADR Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60040
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60040R
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60040A
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | A Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60040AR
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | AR Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60040D
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60040AD
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | AD Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60040ADR
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | ADR Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60045
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60045R
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60045A
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | A Common Cathode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60045AR
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | AR Common Anode | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60045D
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60045AD
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | AD Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60045ADR
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | 0.69 | ADR Doubler | 1 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60060
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | 0.75 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60060R
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | 0.75 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60060A
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | 0.75 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60060AR
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | 0.75 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60060D
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | 0.75 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60060AD
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | 0.75 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT60060ADR
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | 0.75 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600100
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | 0.74 | Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600100R
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | 0.74 | Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600100A
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | 0.74 | A Common Cathode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600100AR
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | 0.74 | AR Common Anode | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600100D
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | 0.74 | Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600100AD
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | 0.74 | AD Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600100ADR
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | 0.74 | ADR Doubler | 1 | 8 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600150
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | 0.8 | Common Cathode | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600150R
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | 0.8 | Common Anode | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600150A
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | 0.8 | A Common Cathode | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600150AR
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | 0.8 | AR Common Anode | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600150D
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | 0.8 | Doubler | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600150AD
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | 0.8 | AD Doubler | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600150ADR
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | 0.8 | ADR Doubler | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600200
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | 0.82 | Common Cathode | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600200R
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | 0.82 | Common Anode | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600200A
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | 0.82 | A Common Cathode | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600200AR
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | 0.82 | AR Common Anode | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600200D
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | 0.82 | Doubler | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600200AD
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | 0.82 | AD Doubler | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT600200ADR
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | 0.82 | ADR Doubler | 4 | 10 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT601200
|
![]() |
Active | 200 | 600 | 300 | 125 | 5200 | 0.96 | 0.86 | Common Cathode | 5 | 20 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT601200R
|
![]() |
Active | 200 | 600 | 300 | 125 | 5200 | 0.96 | 0.86 | Common Anode | 5 | 20 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT601200A
|
![]() |
Active | 200 | 600 | 300 | 125 | 5200 | 0.96 | 0.86 | A Common Cathode | 5 | 20 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT601200AR
|
![]() |
Active | 200 | 600 | 300 | 125 | 5200 | 0.96 | 0.86 | AR Common Anode | 5 | 20 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT601200D
|
![]() |
Active | 200 | 600 | 300 | 125 | 5200 | 0.96 | 0.86 | Doubler | 5 | 20 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT601200AD
|
![]() |
Active | 200 | 600 | 300 | 125 | 5200 | 0.96 | 0.86 | AD Doubler | 5 | 20 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRTT601200ADR
|
![]() |
Active | 200 | 600 | 300 | 125 | 5200 | 0.96 | 0.86 | ADR Doubler | 5 | 20 | -55°C to +150°C | TO-240AA (Isolated) | ||
|
MBRT12020
|
![]() |
Active | 20 | 120 | 60 | 125 | 800 | 0.7 | - | Common Cathode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12020R
|
![]() |
Active | 20 | 120 | 60 | 125 | 800 | 0.7 | - | Common Anode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12030
|
![]() |
Active | 30 | 120 | 60 | 125 | 800 | 0.7 | - | Common Cathode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12030R
|
![]() |
Active | 30 | 120 | 60 | 125 | 800 | 0.7 | - | Common Anode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12035
|
![]() |
Active | 35 | 120 | 60 | 125 | 800 | 0.7 | - | Common Cathode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12035R
|
![]() |
Active | 35 | 120 | 60 | 125 | 800 | 0.7 | - | Common Anode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12040
|
![]() |
Active | 40 | 120 | 60 | 125 | 800 | 0.7 | - | Common Cathode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12040R
|
![]() |
Active | 40 | 120 | 60 | 125 | 800 | 0.7 | - | Common Anode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12045
|
![]() |
Active | 45 | 120 | 60 | 125 | 800 | 0.7 | - | Common Cathode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12045R
|
![]() |
Active | 45 | 120 | 60 | 125 | 800 | 0.7 | - | Common Anode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12060
|
![]() |
Active | 60 | 120 | 60 | 125 | 800 | 0.75 | - | Common Cathode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12060R
|
![]() |
Active | 60 | 120 | 60 | 125 | 800 | 0.75 | - | Common Anode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12080
|
![]() |
Active | 80 | 120 | 60 | 125 | 800 | 0.84 | - | Common Cathode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12080R
|
![]() |
Active | 80 | 120 | 60 | 125 | 800 | 0.84 | - | Common Anode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12090
|
![]() |
Active | 90 | 120 | 60 | 125 | 800 | 0.84 | - | Common Cathode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT12090R
|
![]() |
Active | 90 | 120 | 60 | 125 | 800 | 0.84 | - | Common Anode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT120100
|
![]() |
Active | 100 | 120 | 60 | 125 | 800 | 0.84 | - | Common Cathode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT120100R
|
![]() |
Active | 100 | 120 | 60 | 125 | 800 | 0.84 | - | Common Anode | 1 | 2 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT121150
|
![]() |
Active | 150 | 120 | 60 | 125 | 800 | 0.88 | - | Common Cathode | 1 | 3 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT121150R
|
![]() |
Active | 150 | 120 | 60 | 125 | 800 | 0.88 | - | Common Anode | 1 | 3 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT121200
|
![]() |
Active | 200 | 120 | 60 | 125 | 800 | 0.92 | - | Common Cathode | 1 | 3 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT121200R
|
![]() |
Active | 200 | 120 | 60 | 125 | 800 | 0.92 | - | Common Anode | 1 | 3 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20020
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20020R
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20030
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20030R
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20035
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20035R
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20040
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20040R
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20045
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20045R
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20060
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20060R
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20080
|
![]() |
Active | 80 | 200 | 100 | 125 | 1500 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20080R
|
![]() |
Active | 80 | 200 | 100 | 125 | 1500 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20090
|
![]() |
Active | 90 | 200 | 100 | 125 | 1500 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT20090R
|
![]() |
Active | 90 | 200 | 100 | 125 | 1500 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT200100
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT200100R
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT200150
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | - | Common Cathode | 3 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT200150R
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | - | Common Anode | 3 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT200200
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | - | Common Cathode | 3 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT200200R
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | - | Common Anode | 3 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30020
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30020R
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30030
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30030R
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30035
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30035R
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30040
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30040R
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30045
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30045R
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30060
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30060R
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30090
|
![]() |
Active | 90 | 300 | 150 | 125 | 2000 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT30090R
|
![]() |
Active | 90 | 300 | 150 | 125 | 2000 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT300100
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT300100R
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT300150
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | - | Common Cathode | 3 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT300150R
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | - | Common Anode | 3 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT300200
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | - | Common Cathode | 3 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT300200R
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | - | Common Anode | 3 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT301200
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.9 | - | Common Cathode | 4 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT301200R
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.9 | - | Common Anode | 4 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40020
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | - | Common Cathode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40020R
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | - | Common Anode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40030
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | - | Common Cathode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40030R
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | - | Common Anode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40035
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | - | Common Cathode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40035R
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | - | Common Anode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40040
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | - | Common Cathode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40040R
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | - | Common Anode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40045
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | - | Common Cathode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40045R
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | - | Common Anode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40060
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40060R
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40080
|
![]() |
Active | 80 | 400 | 200 | 125 | 3000 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40080R
|
![]() |
Active | 80 | 400 | 200 | 125 | 3000 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40090
|
![]() |
Active | 90 | 400 | 200 | 125 | 3000 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT40090R
|
![]() |
Active | 90 | 400 | 200 | 125 | 3000 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT400100
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT400100R
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT400150
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | - | Common Cathode | 3 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT400150R
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | - | Common Anode | 3 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT400200
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | - | Common Cathode | 3 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT400200R
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | - | Common Anode | 3 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT401200
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.9 | - | Common Cathode | 4 | 15 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT401200R
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.9 | - | Common Anode | 4 | 15 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT401150AD
|
![]() |
Active | 150 | 400 | 200 | 125 | 3400 | 0.85 | - | AD Doubler | 4 | 15 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT401150ADR
|
![]() |
Active | 150 | 400 | 200 | 125 | 3400 | 0.85 | - | ADR Doubler | 4 | 15 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT401150D
|
![]() |
Active | 150 | 400 | 200 | 125 | 3400 | 0.85 | - | Doubler | 4 | 15 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT402200AD
|
![]() |
Active | 200 | 400 | 200 | 125 | 3400 | 0.88 | - | AD Doubler | 4 | 15 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT402200ADR
|
![]() |
Active | 200 | 400 | 200 | 125 | 3400 | 0.88 | - | ADR Doubler | 4 | 15 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT402200D
|
![]() |
Active | 200 | 400 | 200 | 125 | 3400 | 0.88 | - | Doubler | 4 | 15 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60020
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | - | Common Cathode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60020R
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | - | Common Anode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60030
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | - | Common Cathode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60030R
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | - | Common Anode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60035
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | - | Common Cathode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60035R
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | - | Common Anode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60040
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | - | Common Cathode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60040R
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | - | Common Anode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60045
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | - | Common Cathode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60045R
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | - | Common Anode | 1 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60060
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60060R
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60080
|
![]() |
Active | 80 | 600 | 300 | 125 | 4000 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60080R
|
![]() |
Active | 80 | 600 | 300 | 125 | 4000 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60090
|
![]() |
Active | 90 | 600 | 300 | 125 | 4000 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT60090R
|
![]() |
Active | 90 | 600 | 300 | 125 | 4000 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT600100
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | - | Common Cathode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT600100R
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | - | Common Anode | 1 | 8 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT600150
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | - | Common Cathode | 4 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT600150R
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | - | Common Anode | 4 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT600200
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | - | Common Cathode | 4 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRT600200R
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | - | Common Anode | 4 | 10 | -55°C to +150°C | TO-244AB (Isolated) | ||
|
MBRTH600100AD
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | - | AD Doubler | 1 | 8 | -55°C to +175°C | TO-244AB (Isolated) | ||
|
MBRTH600100ADR
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | - | ADR Doubler | 1 | 8 | -55°C to +175°C | TO-244AB (Isolated) | ||
|
MBRTH600100D
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | - | Doubler | 1 | 8 | -55°C to +175°C | TO-244AB (Isolated) | ||
|
MBRKA801100
|
![]() |
Active | 100 | 800 | 400 | 100 | 6200 | 0.82 | 0.75 | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Three Tower KA (Isolated) | ||
|
MBRKA801100R
|
![]() |
Active | 100 | 800 | 400 | 100 | 6200 | 0.82 | 0.75 | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Three Tower KA (Isolated) | ||
|
MBRKA801150
|
![]() |
Active | 150 | 800 | 400 | 100 | 6200 | 0.86 | 0.76 | Common Cathode | 5 | 30 | -55°C to +150°C | Heavy Three Tower KA (Isolated) | ||
|
MBRKA801150R
|
![]() |
Active | 150 | 800 | 400 | 100 | 6200 | 0.86 | 0.76 | Common Anode | 5 | 30 | -55°C to +150°C | Heavy Three Tower KA (Isolated) | ||
|
MBRKA801200
|
![]() |
Active | 200 | 800 | 400 | 100 | 6200 | 0.9 | 0.8 | Common Cathode | 5 | 30 | -55°C to +150°C | Heavy Three Tower KA (Isolated) | ||
|
MBRKA801200R
|
![]() |
Active | 200 | 800 | 400 | 100 | 6200 | 0.9 | 0.8 | Common Anode | 5 | 30 | -55°C to +150°C | Heavy Three Tower KA (Isolated) | ||
|
MBRTA60020
|
![]() |
Active | 20 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60020R
|
![]() |
Active | 20 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60030
|
![]() |
Active | 30 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60030R
|
![]() |
Active | 30 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60035
|
![]() |
Active | 35 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60035R
|
![]() |
Active | 35 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60040
|
![]() |
Active | 40 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60040R
|
![]() |
Active | 40 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60045
|
![]() |
Active | 45 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60045R
|
![]() |
Active | 45 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60060
|
![]() |
Active | 60 | 600 | 300 | 100 | 4000 | 0.75 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60060R
|
![]() |
Active | 60 | 600 | 300 | 100 | 4000 | 0.75 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60080
|
![]() |
Active | 80 | 600 | 300 | 100 | 4000 | 0.82 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA60080R
|
![]() |
Active | 80 | 600 | 300 | 100 | 4000 | 0.82 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA600100
|
![]() |
Active | 100 | 600 | 300 | 100 | 4000 | 0.84 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA600100R
|
![]() |
Active | 100 | 600 | 300 | 100 | 4000 | 0.84 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA600150
|
![]() |
Active | 150 | 600 | 300 | 100 | 4000 | 0.88 | - | Common Cathode | 4 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA600150R
|
![]() |
Active | 150 | 600 | 300 | 100 | 4000 | 0.88 | - | Common Anode | 4 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA600200
|
![]() |
Active | 200 | 600 | 300 | 100 | 4000 | 0.92 | - | Common Cathode | 4 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA600200R
|
![]() |
Active | 200 | 600 | 300 | 100 | 4000 | 0.92 | - | Common Anode | 4 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA601200
|
![]() |
Active | 200 | 600 | 300 | 100 | 4800 | 0.9 | - | Common Cathode | 6 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA601200R
|
![]() |
Active | 200 | 600 | 300 | 100 | 4800 | 0.9 | - | Common Anode | 6 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80020
|
![]() |
Active | 20 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80020R
|
![]() |
Active | 20 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80030
|
![]() |
Active | 30 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80030R
|
![]() |
Active | 30 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80035
|
![]() |
Active | 35 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80035R
|
![]() |
Active | 35 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80040
|
![]() |
Active | 40 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80040R
|
![]() |
Active | 40 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80045
|
![]() |
Active | 45 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80045R
|
![]() |
Active | 45 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80060
|
![]() |
Active | 60 | 800 | 400 | 100 | 6000 | 0.78 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80060R
|
![]() |
Active | 60 | 800 | 400 | 100 | 6000 | 0.78 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80080
|
![]() |
Active | 80 | 800 | 400 | 100 | 6000 | 0.84 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA80080R
|
![]() |
Active | 80 | 800 | 400 | 100 | 6000 | 0.84 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA800100
|
![]() |
Active | 100 | 800 | 400 | 100 | 6000 | 0.84 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA800100R
|
![]() |
Active | 100 | 800 | 400 | 100 | 6000 | 0.84 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801100
|
![]() |
Active | 100 | 800 | 400 | 100 | 6000 | 0.84 | - | Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801100R
|
![]() |
Active | 100 | 800 | 400 | 100 | 6100 | 0.84 | - | Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801100A
|
![]() |
Active | 100 | 800 | 400 | 100 | 6100 | 0.84 | - | A Common Cathode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801100AR
|
![]() |
Active | 100 | 800 | 400 | 100 | 6100 | 0.84 | - | AR Common Anode | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801100D
|
![]() |
Active | 100 | 800 | 400 | 100 | 6100 | 0.84 | - | Doubler | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801100AD
|
![]() |
Active | 100 | 800 | 400 | 100 | 6100 | 0.84 | - | AD Doubler | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801100ADR
|
![]() |
Active | 100 | 800 | 400 | 100 | 6100 | 0.84 | - | ADR Doubler | 1 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA800150
|
![]() |
Active | 150 | 800 | 400 | 100 | 6000 | 0.88 | - | Common Cathode | 5 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA800150R
|
![]() |
Active | 150 | 800 | 400 | 100 | 6000 | 0.88 | - | Common Anode | 5 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801150
|
![]() |
Active | 150 | 800 | 400 | 100 | 6200 | 0.86 | - | Common Cathode | 5 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801150R
|
![]() |
Active | 150 | 800 | 400 | 100 | 6200 | 0.86 | - | Common Anode | 5 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA800200
|
![]() |
Active | 200 | 800 | 400 | 100 | 6000 | 0.92 | - | Common Cathode | 5 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA800200R
|
![]() |
Active | 200 | 800 | 400 | 100 | 6000 | 0.92 | - | Common Anode | 5 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801200
|
![]() |
Active | 200 | 800 | 400 | 100 | 6200 | 0.91 | - | Common Cathode | 5 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRTA801200R
|
![]() |
Active | 200 | 800 | 400 | 100 | 6200 | 0.91 | - | Common Anode | 5 | 10 | -55°C to +150°C | Heavy Three Tower (Isolated) | ||
|
MBRQ200150CT
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | - | Common Cathode | 3 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ200150CTR
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | - | Common Anode | 3 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ200200CT
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | - | Common Cathode | 3 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ200200CTR
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | - | Common Anode | 3 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ302150CT
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | Common Cathode | 3 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ302150CTR
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | Common Anode | 3 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ302200CT
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | Common Cathode | 3 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ302200CTR
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | Common Anode | 3 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ400100CT
|
![]() |
Active | 100 | 400 | 200 | 125 | 3300 | 0.84 | 0.74 | Common Cathode | 1 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ400100CTR
|
![]() |
Active | 100 | 400 | 200 | 125 | 3300 | 0.84 | 0.74 | Common Anode | 1 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ401100CT
|
![]() |
Active | 100 | 400 | 200 | 125 | 3300 | 0.8 | - | Common Cathode | 1 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ401100CTR
|
![]() |
Active | 100 | 400 | 200 | 125 | 3300 | 0.8 | - | Common Anode | 1 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ401150CT
|
![]() |
Active | 150 | 400 | 200 | 125 | 3300 | 0.86 | - | Common Cathode | 0.4 | 2 | -55°C to +175°C | Twin Tower Q | ||
|
MBRQ401150CTR
|
![]() |
Active | 150 | 400 | 200 | 125 | 3300 | 0.86 | - | Common Anode | 0.4 | 2 | -55°C to +175°C | Twin Tower Q | ||
|
MBRQ402150CT
|
![]() |
Active | 150 | 400 | 200 | 125 | 3400 | 0.85 | 0.74 | Common Cathode | 4 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ402150CTR
|
![]() |
Active | 150 | 400 | 200 | 125 | 3400 | 0.85 | 0.74 | Common Anode | 4 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ400200CT
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.9 | 0.82 | Common Cathode | 3 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ400200CTR
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.9 | 0.82 | Common Anode | 3 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ402200CT
|
![]() |
Active | 200 | 400 | 200 | 125 | 3400 | 0.9 | 0.82 | Common Cathode | 4 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ402200CTR
|
![]() |
Active | 200 | 400 | 200 | 125 | 3400 | 0.9 | 0.82 | Common Anode | 4 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ600100CT
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | - | Common Cathode | 1 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ600100CTR
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | - | Common Anode | 1 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ601100CT
|
![]() |
Active | 100 | 600 | 300 | 125 | 5200 | 0.8 | - | Common Cathode | 1 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ601100CTR
|
![]() |
Active | 100 | 600 | 300 | 125 | 5200 | 0.8 | - | Common Anode | 1 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ601150CT
|
![]() |
Active | 150 | 600 | 300 | 125 | 5200 | 0.86 | - | Common Cathode | 4 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ601150CTR
|
![]() |
Active | 150 | 600 | 300 | 125 | 5200 | 0.86 | - | Common Anode | 4 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ600200CT
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.9 | 0.83 | Common Cathode | 4 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ600200CTR
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.9 | 0.83 | Common Anode | 4 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ601200CT
|
![]() |
Active | 200 | 600 | 300 | 125 | 5200 | 0.9 | 0.83 | Common Cathode | 5 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBRQ601200CTR
|
![]() |
Active | 200 | 600 | 300 | 125 | 5200 | 0.9 | 0.83 | Common Anode | 5 | 20 | -55°C to +150°C | Twin Tower Q | ||
|
MBR12020CT
|
![]() |
Active | 20 | 120 | 60 | 125 | 800 | 0.7 | 0.65 | Common Cathode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12020CTR
|
![]() |
Active | 20 | 120 | 60 | 125 | 800 | 0.7 | 0.65 | Common Anode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12030CT
|
![]() |
Active | 30 | 120 | 60 | 125 | 800 | 0.7 | 0.65 | Common Cathode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12030CTR
|
![]() |
Active | 30 | 120 | 60 | 125 | 800 | 0.7 | 0.65 | Common Anode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12035CT
|
![]() |
Active | 35 | 120 | 60 | 125 | 800 | 0.7 | 0.65 | Common Cathode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12035CTR
|
![]() |
Active | 35 | 120 | 60 | 125 | 800 | 0.7 | 0.65 | Common Anode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12040CT
|
![]() |
Active | 40 | 120 | 60 | 125 | 800 | 0.7 | 0.65 | Common Cathode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12040CTR
|
![]() |
Active | 40 | 120 | 60 | 125 | 800 | 0.7 | 0.65 | Common Anode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12045CT
|
![]() |
Active | 45 | 120 | 60 | 125 | 800 | 0.7 | 0.65 | Common Cathode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12045CTR
|
![]() |
Active | 45 | 120 | 60 | 125 | 800 | 0.7 | 0.65 | Common Anode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12060CT
|
![]() |
Active | 60 | 120 | 60 | 125 | 800 | 0.75 | 0.7 | Common Cathode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12060CTR
|
![]() |
Active | 60 | 120 | 60 | 125 | 800 | 0.75 | 0.7 | Common Anode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12080CT
|
![]() |
Active | 80 | 120 | 60 | 125 | 800 | 0.84 | 0.75 | Common Cathode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12080CTR
|
![]() |
Active | 80 | 120 | 60 | 125 | 800 | 0.84 | 0.75 | Common Anode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12090CT
|
![]() |
Active | 90 | 120 | 60 | 125 | 800 | 0.84 | 0.75 | Common Cathode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR12090CTR
|
![]() |
Active | 90 | 120 | 60 | 125 | 800 | 0.84 | 0.75 | Common Anode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR120100CT
|
![]() |
Active | 100 | 120 | 60 | 125 | 800 | 0.84 | 0.75 | Common Cathode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR120100CTR
|
![]() |
Active | 100 | 120 | 60 | 125 | 800 | 0.84 | 0.75 | Common Anode | 1 | 2 | -55°C to +150°C | Twin Tower | ||
|
MBR121150CT
|
![]() |
Active | 150 | 120 | 60 | 125 | 800 | 0.88 | - | Common Cathode | 1 | 3 | -55°C to +150°C | Twin Tower | ||
|
MBR121150CTR
|
![]() |
Active | 150 | 120 | 60 | 125 | 800 | 0.88 | - | Common Anode | 1 | 3 | -55°C to +150°C | Twin Tower | ||
|
MBR121200CT
|
![]() |
Active | 200 | 120 | 60 | 125 | 800 | 0.92 | - | Common Cathode | 1 | 3 | -55°C to +150°C | Twin Tower | ||
|
MBR121200CTR
|
![]() |
Active | 200 | 120 | 60 | 125 | 800 | 0.92 | - | Common Anode | 1 | 3 | -55°C to +150°C | Twin Tower | ||
|
MBR20020CT
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | 0.65 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20020CTR
|
![]() |
Active | 20 | 200 | 100 | 125 | 1500 | 0.7 | 0.65 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20030CT
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | 0.65 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20030CTR
|
![]() |
Active | 30 | 200 | 100 | 125 | 1500 | 0.7 | 0.65 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20035CT
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | 0.65 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20035CTR
|
![]() |
Active | 35 | 200 | 100 | 125 | 1500 | 0.7 | 0.65 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20040CT
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | 0.65 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20040CTR
|
![]() |
Active | 40 | 200 | 100 | 125 | 1500 | 0.7 | 0.65 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20045CT
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | 0.65 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20045CTR
|
![]() |
Active | 45 | 200 | 100 | 125 | 1500 | 0.7 | 0.65 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20060CT
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | 0.7 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20060CTR
|
![]() |
Active | 60 | 200 | 100 | 125 | 1500 | 0.75 | 0.7 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20080CT
|
![]() |
Active | 80 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20080CTR
|
![]() |
Active | 80 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20090CT
|
![]() |
Active | 90 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR20090CTR
|
![]() |
Active | 90 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR200100CT
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR200100CTR
|
![]() |
Active | 100 | 200 | 100 | 125 | 1500 | 0.84 | 0.74 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR200150CT
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | 0.78 | Common Cathode | 3 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR200150CTR
|
![]() |
Active | 150 | 200 | 100 | 125 | 1500 | 0.88 | 0.78 | Common Anode | 3 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR200200CT
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | 0.82 | Common Cathode | 3 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR200200CTR
|
![]() |
Active | 200 | 200 | 100 | 125 | 1500 | 0.92 | 0.82 | Common Anode | 3 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30020CT
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | 0.65 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30020CTR
|
![]() |
Active | 20 | 300 | 150 | 125 | 2000 | 0.7 | 0.65 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30030CT
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | 0.65 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30030CTR
|
![]() |
Active | 30 | 300 | 150 | 125 | 2000 | 0.7 | 0.65 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30035CT
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | 0.65 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30035CTR
|
![]() |
Active | 35 | 300 | 150 | 125 | 2000 | 0.7 | 0.65 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30040CT
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | 0.65 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30040CTR
|
![]() |
Active | 40 | 300 | 150 | 125 | 2000 | 0.7 | 0.65 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30045CT
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | 0.65 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30045CTR
|
![]() |
Active | 45 | 300 | 150 | 125 | 2000 | 0.7 | 0.65 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30060CT
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | 0.7 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30060CTR
|
![]() |
Active | 60 | 300 | 150 | 125 | 2000 | 0.75 | 0.7 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30080CT
|
![]() |
Active | 80 | 300 | 150 | 125 | 2000 | 0.84 | 0.76 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30080CTR
|
![]() |
Active | 80 | 300 | 150 | 125 | 2000 | 0.84 | 0.76 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30090CT
|
![]() |
Active | 90 | 300 | 150 | 125 | 2000 | 0.84 | 0.76 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR30090CTR
|
![]() |
Active | 90 | 300 | 150 | 125 | 2000 | 0.84 | 0.76 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR300100CT
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | 0.76 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR300100CTR
|
![]() |
Active | 100 | 300 | 150 | 125 | 2000 | 0.84 | 0.76 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR300150CT
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | Common Cathode | 3 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR300150CTR
|
![]() |
Active | 150 | 300 | 150 | 125 | 2000 | 0.88 | 0.8 | Common Anode | 3 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR300200CT
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | Common Cathode | 3 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR300200CTR
|
![]() |
Active | 200 | 300 | 150 | 125 | 2000 | 0.92 | 0.82 | Common Anode | 3 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR40020CT
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | 0.65 | Common Cathode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR40020CTR
|
![]() |
Active | 20 | 400 | 200 | 125 | 3000 | 0.7 | 0.65 | Common Anode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR40030CT
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | 0.65 | Common Cathode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR40030CTR
|
![]() |
Active | 30 | 400 | 200 | 125 | 3000 | 0.7 | 0.65 | Common Anode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR40035CT
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | 0.65 | Common Cathode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR40035CTR
|
![]() |
Active | 35 | 400 | 200 | 125 | 3000 | 0.7 | 0.65 | Common Anode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR40040CT
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | 0.65 | Common Cathode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR40040CTR
|
![]() |
Active | 40 | 400 | 200 | 125 | 3000 | 0.7 | 0.65 | Common Anode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR40045CT
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | 0.65 | Common Cathode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR40045CTR
|
![]() |
Active | 45 | 400 | 200 | 125 | 3000 | 0.7 | 0.65 | Common Anode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR40060CT
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | 0.7 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR40060CTR
|
![]() |
Active | 60 | 400 | 200 | 125 | 3000 | 0.75 | 0.7 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR40080CT
|
![]() |
Active | 80 | 400 | 200 | 125 | 3000 | 0.84 | 0.76 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR40080CTR
|
![]() |
Active | 80 | 400 | 200 | 125 | 3000 | 0.84 | 0.76 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR40090CT
|
![]() |
Active | 90 | 400 | 200 | 125 | 3000 | 0.84 | 0.76 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR40090CTR
|
![]() |
Active | 90 | 400 | 200 | 125 | 3000 | 0.84 | 0.76 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR400100CT
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | 0.76 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR400100CTR
|
![]() |
Active | 100 | 400 | 200 | 125 | 3000 | 0.84 | 0.76 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR400150CT
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | 0.8 | Common Cathode | 3 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR400150CTR
|
![]() |
Active | 150 | 400 | 200 | 125 | 3000 | 0.88 | 0.8 | Common Anode | 3 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR400200CT
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | 0.82 | Common Cathode | 3 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR400200CTR
|
![]() |
Active | 200 | 400 | 200 | 125 | 3000 | 0.92 | 0.82 | Common Anode | 3 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60020CT
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | 0.7 | Common Cathode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60020CTR
|
![]() |
Active | 20 | 600 | 300 | 125 | 4000 | 0.75 | 0.7 | Common Anode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60030CT
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | 0.7 | Common Cathode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60030CTR
|
![]() |
Active | 30 | 600 | 300 | 125 | 4000 | 0.75 | 0.7 | Common Anode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60035CT
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | 0.7 | Common Cathode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60035CTR
|
![]() |
Active | 35 | 600 | 300 | 125 | 4000 | 0.75 | 0.7 | Common Anode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60040CT
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | 0.7 | Common Cathode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60040CTR
|
![]() |
Active | 40 | 600 | 300 | 125 | 4000 | 0.75 | 0.7 | Common Anode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60045CT
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | 0.7 | Common Cathode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60045CTR
|
![]() |
Active | 45 | 600 | 300 | 125 | 4000 | 0.75 | 0.7 | Common Anode | 1 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR60060CT
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | 0.75 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR60060CTR
|
![]() |
Active | 60 | 600 | 300 | 125 | 4000 | 0.8 | 0.75 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR60080CT
|
![]() |
Active | 80 | 600 | 300 | 125 | 4000 | 0.84 | 0.77 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR60080CTR
|
![]() |
Active | 80 | 600 | 300 | 125 | 4000 | 0.84 | 0.77 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR60090CT
|
![]() |
Active | 90 | 600 | 300 | 125 | 4000 | 0.84 | 0.77 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR60090CTR
|
![]() |
Active | 90 | 600 | 300 | 125 | 4000 | 0.84 | 0.77 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR600100CT
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | 0.77 | Common Cathode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR600100CTR
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | 0.77 | Common Anode | 1 | 8 | -55°C to +150°C | Twin Tower | ||
|
MBR600150CT
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | 0.8 | Common Cathode | 4 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR600150CTR
|
![]() |
Active | 150 | 600 | 300 | 125 | 4000 | 0.88 | 0.8 | Common Anode | 4 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR600200CT
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | - | Common Cathode | 4 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR600200CTR
|
![]() |
Active | 200 | 600 | 300 | 125 | 4000 | 0.92 | - | Common Anode | 4 | 10 | -55°C to +150°C | Twin Tower | ||
|
MBR601200CT
|
![]() |
Active | 200 | 600 | 300 | 125 | 4800 | 0.9 | - | Common Cathode | 5 | 20 | -55°C to +150°C | Twin Tower | ||
|
MBR601200CTR
|
![]() |
Active | 200 | 600 | 300 | 125 | 4800 | 0.9 | - | Common Anode | 5 | 20 | -55°C to +150°C | Twin Tower | ||
|
MBRH600100CTD
|
![]() |
Active | 100 | 600 | 300 | 125 | 4000 | 0.84 | - | Doubler | 1 | 8 | -55°C to +175°C | Twin Tower | ||
|
MBRA60020CT
|
![]() |
Active | 20 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60020CTR
|
![]() |
Active | 20 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60030CT
|
![]() |
Active | 30 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60030CTR
|
![]() |
Active | 30 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60035CT
|
![]() |
Active | 35 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60035CTR
|
![]() |
Active | 35 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60040CT
|
![]() |
Active | 40 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60040CTR
|
![]() |
Active | 40 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60045CT
|
![]() |
Active | 45 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60045CTR
|
![]() |
Active | 45 | 600 | 300 | 100 | 4000 | 0.7 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60060CT
|
![]() |
Active | 60 | 600 | 300 | 100 | 4000 | 0.75 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60060CTR
|
![]() |
Active | 60 | 600 | 300 | 100 | 4000 | 0.75 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60080CT
|
![]() |
Active | 80 | 600 | 300 | 100 | 4000 | 0.84 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA60080CTR
|
![]() |
Active | 80 | 600 | 300 | 100 | 4000 | 0.84 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA600100CT
|
![]() |
Active | 100 | 600 | 300 | 100 | 4000 | 0.84 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA600100CTR
|
![]() |
Active | 100 | 600 | 300 | 100 | 4000 | 0.84 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA600150CT
|
![]() |
Active | 150 | 600 | 300 | 100 | 4000 | 0.88 | - | Common Cathode | 4 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA600150CTR
|
![]() |
Active | 150 | 600 | 300 | 100 | 4000 | 0.88 | - | Common Anode | 4 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA601200CT
|
![]() |
Active | 200 | 600 | 300 | 100 | 4800 | 0.9 | - | Common Cathode | 4 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA601200CTR
|
![]() |
Active | 200 | 600 | 300 | 100 | 4800 | 0.9 | - | Common Anode | 4 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80020CT
|
![]() |
Active | 20 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80020CTR
|
![]() |
Active | 20 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80030CT
|
![]() |
Active | 30 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80030CTR
|
![]() |
Active | 30 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80035CT
|
![]() |
Active | 35 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80035CTR
|
![]() |
Active | 35 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80040CT
|
![]() |
Active | 40 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80040CTR
|
![]() |
Active | 40 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80045CT
|
![]() |
Active | 45 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80045CTR
|
![]() |
Active | 45 | 800 | 400 | 100 | 6000 | 0.72 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80060CT
|
![]() |
Active | 60 | 800 | 400 | 100 | 6000 | 0.78 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80060CTR
|
![]() |
Active | 60 | 800 | 400 | 100 | 6000 | 0.78 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80080CT
|
![]() |
Active | 80 | 800 | 400 | 100 | 6000 | 0.84 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA80080CTR
|
![]() |
Active | 80 | 800 | 400 | 100 | 6000 | 0.84 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA800100CT
|
![]() |
Active | 100 | 800 | 400 | 100 | 6000 | 0.84 | - | Common Cathode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA800100CTR
|
![]() |
Active | 100 | 800 | 400 | 100 | 6000 | 0.84 | - | Common Anode | 1 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA801150CT
|
![]() |
Active | 150 | 800 | 400 | 100 | 6200 | 0.86 | - | Common Cathode | 5 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA801150CTR
|
![]() |
Active | 150 | 800 | 400 | 100 | 6200 | 0.86 | - | Common Anode | 5 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA801200CT
|
![]() |
Active | 200 | 800 | 400 | 100 | 6200 | 0.91 | - | Common Cathode | 5 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRA801200CTR
|
![]() |
Active | 200 | 800 | 400 | 100 | 6200 | 0.91 | - | Common Anode | 5 | 30 | -55°C to +150°C | Heavy Twin Tower | ||
|
MBRH12020
|
![]() |
Active | 20 | 120 | 120 | 125 | 2000 | 0.7 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12020R
|
![]() |
Active | 20 | 120 | 120 | 125 | 2000 | 0.7 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12030
|
![]() |
Active | 30 | 120 | 120 | 125 | 2000 | 0.7 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12030R
|
![]() |
Active | 30 | 120 | 120 | 125 | 2000 | 0.7 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12035
|
![]() |
Active | 35 | 120 | 120 | 125 | 2000 | 0.7 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12035R
|
![]() |
Active | 35 | 120 | 120 | 125 | 2000 | 0.7 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12040
|
![]() |
Active | 40 | 120 | 120 | 125 | 2000 | 0.7 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12040R
|
![]() |
Active | 40 | 120 | 120 | 125 | 2000 | 0.7 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12045
|
![]() |
Active | 45 | 120 | 120 | 125 | 2000 | 0.7 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12045R
|
![]() |
Active | 45 | 120 | 120 | 125 | 2000 | 0.7 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12060
|
![]() |
Active | 60 | 120 | 120 | 125 | 2000 | 0.75 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12060R
|
![]() |
Active | 60 | 120 | 120 | 125 | 2000 | 0.75 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12080
|
![]() |
Active | 80 | 120 | 120 | 125 | 2000 | 0.84 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH12080R
|
![]() |
Active | 80 | 120 | 120 | 125 | 2000 | 0.84 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH120100
|
![]() |
Active | 100 | 120 | 120 | 125 | 2000 | 0.84 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH120100R
|
![]() |
Active | 100 | 120 | 120 | 125 | 2000 | 0.84 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH120150
|
![]() |
Active | 150 | 120 | 120 | 125 | 2000 | 0.88 | - | Single (Common Cathode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH120150R
|
![]() |
Active | 150 | 120 | 120 | 125 | 2000 | 0.88 | - | Single (Common Anode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH120200
|
![]() |
Active | 200 | 120 | 120 | 125 | 2000 | 0.92 | - | Single (Common Cathode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH120200R
|
![]() |
Active | 200 | 120 | 120 | 125 | 2000 | 0.92 | - | Single (Common Anode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20020
|
![]() |
Active | 20 | 200 | 200 | 125 | 3000 | 0.7 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20020R
|
![]() |
Active | 20 | 200 | 200 | 125 | 3000 | 0.7 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20030
|
![]() |
Active | 30 | 200 | 200 | 125 | 3000 | 0.7 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20030R
|
![]() |
Active | 30 | 200 | 200 | 125 | 3000 | 0.7 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20035
|
![]() |
Active | 35 | 200 | 200 | 125 | 3000 | 0.7 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20035R
|
![]() |
Active | 35 | 200 | 200 | 125 | 3000 | 0.7 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20040
|
![]() |
Active | 40 | 200 | 200 | 125 | 3000 | 0.7 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20040R
|
![]() |
Active | 40 | 200 | 200 | 125 | 3000 | 0.7 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20045
|
![]() |
Active | 45 | 200 | 200 | 125 | 3000 | 0.7 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20045R
|
![]() |
Active | 45 | 200 | 200 | 125 | 3000 | 0.7 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20060
|
![]() |
Active | 60 | 200 | 200 | 125 | 3000 | 0.75 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20060R
|
![]() |
Active | 60 | 200 | 200 | 125 | 3000 | 0.75 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20080
|
![]() |
Active | 80 | 200 | 200 | 125 | 3000 | 0.84 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH20080R
|
![]() |
Active | 80 | 200 | 200 | 125 | 3000 | 0.84 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH200100
|
![]() |
Active | 100 | 200 | 200 | 125 | 3000 | 0.84 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH200100R
|
![]() |
Active | 100 | 200 | 200 | 125 | 3000 | 0.84 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH200150
|
![]() |
Active | 150 | 200 | 200 | 125 | 3000 | 0.88 | - | Single (Common Cathode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH200150R
|
![]() |
Active | 150 | 200 | 200 | 125 | 3000 | 0.88 | - | Single (Common Anode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH201200
|
![]() |
Active | 200 | 200 | 200 | 125 | 3000 | 0.9 | - | Single (Common Cathode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH201200R
|
![]() |
Active | 200 | 200 | 200 | 125 | 3000 | 0.9 | - | Single (Common Anode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24020
|
![]() |
Active | 20 | 240 | 240 | 125 | 3300 | 0.72 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24020R
|
![]() |
Active | 20 | 240 | 240 | 125 | 3300 | 0.72 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24030
|
![]() |
Active | 30 | 240 | 240 | 125 | 3300 | 0.72 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24030R
|
![]() |
Active | 30 | 240 | 240 | 125 | 3300 | 0.72 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24035
|
![]() |
Active | 35 | 240 | 240 | 125 | 3300 | 0.72 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24035R
|
![]() |
Active | 35 | 240 | 240 | 125 | 3300 | 0.72 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24040
|
![]() |
Active | 40 | 240 | 240 | 125 | 3300 | 0.72 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24040R
|
![]() |
Active | 40 | 240 | 240 | 125 | 3300 | 0.72 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24045
|
![]() |
Active | 45 | 240 | 240 | 125 | 3300 | 0.72 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24045R
|
![]() |
Active | 45 | 240 | 240 | 125 | 3300 | 0.72 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24060
|
![]() |
Active | 60 | 240 | 240 | 125 | 3300 | 0.78 | - | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24060R
|
![]() |
Active | 60 | 240 | 240 | 125 | 3300 | 0.78 | - | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24080
|
![]() |
Active | 80 | 240 | 240 | 125 | 3300 | 0.84 | 0.71 | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH24080R
|
![]() |
Active | 80 | 240 | 240 | 125 | 3300 | 0.84 | 0.71 | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH240100
|
![]() |
Active | 100 | 240 | 240 | 125 | 3300 | 0.84 | 0.71 | Single (Common Cathode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH240100R
|
![]() |
Active | 100 | 240 | 240 | 125 | 3300 | 0.84 | 0.71 | Single (Common Anode) | 1 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH240150
|
![]() |
Active | 150 | 240 | 240 | 125 | 3300 | 0.88 | - | Single (Common Cathode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH240150R
|
![]() |
Active | 150 | 240 | 240 | 125 | 3300 | 0.88 | - | Single (Common Anode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH241200
|
![]() |
Active | 200 | 240 | 240 | 125 | 3300 | 0.92 | - | Single (Common Cathode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
MBRH241200R
|
![]() |
Active | 200 | 240 | 240 | 125 | 3300 | 0.92 | - | Single (Common Anode) | 3 | 20 | -55°C to +150°C | Half Pack (D-67) | ||
|
FST10020
|
![]() |
Active | 20 | 100 | 50 | 125 | 1000 | 0.7 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST10030
|
![]() |
Active | 30 | 100 | 50 | 125 | 1000 | 0.7 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST10035
|
![]() |
Active | 35 | 100 | 50 | 125 | 1000 | 0.7 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST10040
|
![]() |
Active | 40 | 100 | 50 | 125 | 1000 | 0.7 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST10045
|
![]() |
Active | 45 | 100 | 50 | 125 | 1000 | 0.7 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST10060
|
![]() |
Active | 60 | 100 | 50 | 125 | 1000 | 0.75 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST10080
|
![]() |
Active | 80 | 100 | 50 | 125 | 1000 | 0.84 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST100100
|
![]() |
Active | 100 | 100 | 50 | 125 | 1000 | 0.84 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST100150
|
![]() |
Active | 150 | 100 | 50 | 125 | 1000 | 0.88 | - | Dual (Common Cathode) | 3 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST100200
|
![]() |
Active | 200 | 100 | 50 | 125 | 1000 | 0.92 | - | Dual (Common Cathode) | 3 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST12020
|
![]() |
Active | 20 | 120 | 60 | 125 | 1000 | 0.7 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST12030
|
![]() |
Active | 30 | 120 | 60 | 125 | 1000 | 0.7 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST12035
|
![]() |
Active | 35 | 120 | 60 | 125 | 1000 | 0.7 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST12040
|
![]() |
Active | 40 | 120 | 60 | 125 | 1000 | 0.7 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST12045
|
![]() |
Active | 45 | 120 | 60 | 125 | 1000 | 0.7 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST12060
|
![]() |
Active | 60 | 120 | 60 | 125 | 1000 | 0.75 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST12080
|
![]() |
Active | 80 | 120 | 60 | 125 | 1000 | 0.84 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST120100
|
![]() |
Active | 100 | 120 | 60 | 125 | 1000 | 0.84 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST120150
|
![]() |
Active | 150 | 120 | 60 | 125 | 1000 | 0.88 | - | Dual (Common Cathode) | 3 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST120200
|
![]() |
Active | 200 | 120 | 60 | 125 | 1000 | 0.92 | - | Dual (Common Cathode) | 3 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST16020
|
![]() |
Active | 20 | 160 | 80 | 125 | 1000 | 0.75 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST16030
|
![]() |
Active | 30 | 160 | 80 | 125 | 1000 | 0.75 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST16035
|
![]() |
Active | 35 | 160 | 80 | 125 | 1000 | 0.75 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST16040
|
![]() |
Active | 40 | 160 | 80 | 125 | 1000 | 0.75 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST16045
|
![]() |
Active | 45 | 160 | 80 | 125 | 1000 | 0.75 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST16060
|
![]() |
Active | 60 | 160 | 80 | 125 | 1000 | 0.8 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST16080
|
![]() |
Active | 80 | 160 | 80 | 125 | 1000 | 0.84 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST160100
|
![]() |
Active | 100 | 160 | 80 | 125 | 1000 | 0.84 | - | Dual (Common Cathode) | 1 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST160150
|
![]() |
Active | 150 | 160 | 80 | 125 | 1000 | 0.88 | - | Dual (Common Cathode) | 3 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST160200
|
![]() |
Active | 200 | 160 | 80 | 125 | 1000 | 0.92 | - | Dual (Common Cathode) | 3 | 20 | -55°C to +150°C | Power Mod (TO-249AA) | ||
|
FST6310M
|
![]() |
Active | 10 | 60 | 30 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST6315M
|
![]() |
Active | 15 | 60 | 30 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST6320M
|
![]() |
Active | 20 | 60 | 30 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST6330M
|
![]() |
Active | 30 | 60 | 30 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST6340M
|
![]() |
Active | 40 | 60 | 30 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST6345M
|
![]() |
Active | 45 | 60 | 30 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST6360M
|
![]() |
Active | 60 | 60 | 30 | 125 | 600 | 0.75 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST6380M
|
![]() |
Active | 80 | 60 | 30 | 125 | 600 | 0.84 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST63100M
|
![]() |
Active | 100 | 60 | 30 | 125 | 600 | 0.84 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST7320M
|
![]() |
Active | 20 | 70 | 35 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST7330M
|
![]() |
Active | 30 | 70 | 35 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST7335M
|
![]() |
Active | 35 | 70 | 35 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST7340M
|
![]() |
Active | 40 | 70 | 35 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST7345M
|
![]() |
Active | 45 | 70 | 35 | 125 | 600 | 0.7 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST7360M
|
![]() |
Active | 60 | 70 | 35 | 125 | 600 | 0.75 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST7380M
|
![]() |
Active | 80 | 70 | 35 | 125 | 600 | 0.84 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST73100M
|
![]() |
Active | 100 | 70 | 35 | 125 | 600 | 0.84 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST8320M
|
![]() |
Active | 20 | 80 | 40 | 125 | 600 | 0.72 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST8330M
|
![]() |
Active | 30 | 80 | 40 | 125 | 600 | 0.72 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST8335M
|
![]() |
Active | 35 | 80 | 40 | 125 | 600 | 0.72 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST8340M
|
![]() |
Active | 40 | 80 | 40 | 125 | 600 | 0.72 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST8345M
|
![]() |
Active | 45 | 80 | 40 | 125 | 600 | 0.72 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST8360M
|
![]() |
Active | 60 | 80 | 40 | 125 | 600 | 0.78 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST8380M
|
![]() |
Active | 80 | 80 | 40 | 125 | 600 | 0.84 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
FST83100M
|
![]() |
Active | 100 | 80 | 40 | 125 | 600 | 0.84 | - | Dual | 1 | 20 | -55°C to +150°C | Mini Mod (D61-3M) | ||
|
1N5832
|
![]() |
Active | 20 | 40 | 40 | 125 | 800 | 0.7 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
1N5832R
|
![]() |
Active | 20 | 40 | 40 | 125 | 800 | 0.7 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
1N5833
|
![]() |
Active | 30 | 40 | 40 | 125 | 800 | 0.7 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
1N5833R
|
![]() |
Active | 30 | 40 | 40 | 125 | 800 | 0.7 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
1N5834
|
![]() |
Active | 40 | 40 | 40 | 125 | 800 | 0.7 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
1N5834R
|
![]() |
Active | 40 | 40 | 40 | 125 | 800 | 0.7 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
1N6097
|
![]() |
Active | 30 | 50 | 50 | 125 | 800 | 0.7 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
1N6097R
|
![]() |
Active | 30 | 50 | 50 | 125 | 800 | 0.7 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
1N6098
|
![]() |
Active | 40 | 50 | 50 | 125 | 800 | 0.7 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
1N6098R
|
![]() |
Active | 40 | 50 | 50 | 125 | 800 | 0.7 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
SD51
|
![]() |
Active | 45 | 60 | 60 | 125 | 800 | 0.72 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
SD51R
|
![]() |
Active | 45 | 60 | 60 | 125 | 800 | 0.72 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6020
|
![]() |
Active | 20 | 60 | 60 | 125 | 900 | 0.72 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6020R
|
![]() |
Active | 20 | 60 | 60 | 125 | 900 | 0.72 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6030
|
![]() |
Active | 30 | 60 | 60 | 125 | 900 | 0.72 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6030R
|
![]() |
Active | 30 | 60 | 60 | 125 | 900 | 0.72 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6035
|
![]() |
Active | 35 | 60 | 60 | 125 | 900 | 0.72 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6035R
|
![]() |
Active | 35 | 60 | 60 | 125 | 900 | 0.72 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6040
|
![]() |
Active | 40 | 60 | 60 | 125 | 900 | 0.72 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6040R
|
![]() |
Active | 40 | 60 | 60 | 125 | 900 | 0.72 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6045
|
![]() |
Active | 45 | 60 | 60 | 125 | 900 | 0.72 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6045R
|
![]() |
Active | 45 | 60 | 60 | 125 | 900 | 0.72 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6060
|
![]() |
Active | 60 | 60 | 60 | 125 | 900 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6060R
|
![]() |
Active | 60 | 60 | 60 | 125 | 900 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6080
|
![]() |
Active | 80 | 60 | 60 | 125 | 900 | 0.84 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR6080R
|
![]() |
Active | 80 | 60 | 60 | 125 | 900 | 0.84 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR60100
|
![]() |
Active | 100 | 60 | 60 | 125 | 900 | 0.84 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR60100R
|
![]() |
Active | 100 | 60 | 60 | 125 | 900 | 0.84 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR60150
|
![]() |
Active | 150 | 60 | 60 | 125 | 900 | 0.88 | - | Single | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR60150R
|
![]() |
Active | 150 | 60 | 60 | 125 | 900 | 0.88 | - | Single Reverse Polarity | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR60200
|
![]() |
Active | 200 | 60 | 60 | 125 | 900 | 0.92 | - | Single | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR60200R
|
![]() |
Active | 200 | 60 | 60 | 125 | 900 | 0.92 | - | Single Reverse Polarity | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7520
|
![]() |
Active | 20 | 75 | 75 | 125 | 1000 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7520R
|
![]() |
Active | 20 | 75 | 75 | 125 | 1000 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7530
|
![]() |
Active | 30 | 75 | 75 | 125 | 1000 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7530R
|
![]() |
Active | 30 | 75 | 75 | 125 | 1000 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7535
|
![]() |
Active | 35 | 75 | 75 | 125 | 1000 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7535R
|
![]() |
Active | 35 | 75 | 75 | 125 | 1000 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7540
|
![]() |
Active | 40 | 75 | 75 | 125 | 1000 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7540R
|
![]() |
Active | 40 | 75 | 75 | 125 | 1000 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7545
|
![]() |
Active | 45 | 75 | 75 | 125 | 1000 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7545R
|
![]() |
Active | 45 | 75 | 75 | 125 | 1000 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7560
|
![]() |
Active | 60 | 75 | 75 | 125 | 1000 | 0.78 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7560R
|
![]() |
Active | 60 | 75 | 75 | 125 | 1000 | 0.78 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7580
|
![]() |
Active | 80 | 75 | 75 | 125 | 1000 | 0.84 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR7580R
|
![]() |
Active | 80 | 75 | 75 | 125 | 1000 | 0.84 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR75100
|
![]() |
Active | 100 | 75 | 75 | 125 | 1000 | 0.84 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR75100R
|
![]() |
Active | 100 | 75 | 75 | 125 | 1000 | 0.84 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR75150
|
![]() |
Active | 150 | 75 | 75 | 125 | 1000 | 0.88 | - | Single | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR75150R
|
![]() |
Active | 150 | 75 | 75 | 125 | 1000 | 0.88 | - | Single Reverse Polarity | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR75200
|
![]() |
Active | 200 | 75 | 75 | 125 | 1000 | 0.92 | - | Single | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR75200R
|
![]() |
Active | 200 | 75 | 75 | 125 | 1000 | 0.92 | - | Single Reverse Polarity | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8020
|
![]() |
Active | 20 | 80 | 80 | 125 | 1000 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8020R
|
![]() |
Active | 20 | 80 | 80 | 125 | 1000 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8030
|
![]() |
Active | 30 | 80 | 80 | 125 | 1000 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8030R
|
![]() |
Active | 30 | 80 | 80 | 125 | 1000 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8035
|
![]() |
Active | 35 | 80 | 80 | 125 | 1000 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8035R
|
![]() |
Active | 35 | 80 | 80 | 125 | 1000 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8040
|
![]() |
Active | 40 | 80 | 80 | 125 | 1000 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8040R
|
![]() |
Active | 40 | 80 | 80 | 125 | 1000 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8045
|
![]() |
Active | 45 | 80 | 80 | 125 | 1000 | 0.75 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8045R
|
![]() |
Active | 45 | 80 | 80 | 125 | 1000 | 0.75 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8060
|
![]() |
Active | 60 | 80 | 80 | 125 | 1000 | 0.78 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8060R
|
![]() |
Active | 60 | 80 | 80 | 125 | 1000 | 0.78 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8080
|
![]() |
Active | 80 | 80 | 80 | 125 | 1000 | 0.84 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR8080R
|
![]() |
Active | 80 | 80 | 80 | 125 | 1000 | 0.84 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR80100
|
![]() |
Active | 100 | 80 | 80 | 125 | 1000 | 0.84 | - | Single | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR80100R
|
![]() |
Active | 100 | 80 | 80 | 125 | 1000 | 0.84 | - | Single Reverse Polarity | 1 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR80150
|
![]() |
Active | 150 | 80 | 80 | 125 | 1000 | 0.88 | - | Single | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR80150R
|
![]() |
Active | 150 | 80 | 80 | 125 | 1000 | 0.88 | - | Single Reverse Polarity | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR80200
|
![]() |
Active | 200 | 80 | 80 | 125 | 1000 | 0.92 | - | Single | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) | ||
|
MBR80200R
|
![]() |
Active | 200 | 80 | 80 | 125 | 1000 | 0.92 | - | Single Reverse Polarity | 3 | 20 | -55°C to +150°C | DO-5 Stud (DO-203AB) |
